Beyond RNA Velocity: How PHLOWER’s Topological Approach Maps Complex Cell Development Paths

Revolutionizing Single-Cell Analysis with Mathematical Topology

In the rapidly evolving field of single-cell biology, researchers have long sought methods to accurately trace the complex branching paths that cells follow during differentiation. Traditional approaches like RNA velocity have provided valuable insights but faced limitations in reconstructing complete differentiation trees. Enter PHLOWER—a groundbreaking computational method published in Nature Methods that leverages Hodge Laplacian mathematics and topological data analysis to reveal previously hidden aspects of cellular development.

The Mathematical Foundation: From Vector Fields to Cellular Trajectories

PHLOWER builds upon the mathematical framework of Hodge Laplacian (HL) decomposition, which has previously been applied to RNA velocity analysis. While earlier methods used HL to visualize vector field components, they couldn’t reconstruct complete differentiation trees or precisely allocate cells along these structures. PHLOWER’s innovation lies in its specialized application of the harmonic component from Hodge decomposition to directly map cell differentiation events.

The method represents single-cell data as a simplicial complex—a mathematical structure comprising nodes (0-simplices representing individual cells), edges (1-simplices representing differentiation events), and triangles (2-simplices representing relationships between multiple cells). This representation enables PHLOWER to apply first-order Hodge Laplacian analysis, which describes how edges relate to each other through both nodes (lower-adjacency) and triangular faces (upper-adjacency).

Building Cellular Maps Through Topological Holes

PHLOWER’s most ingenious innovation involves creating and analyzing topological “holes” that correspond to differentiation trajectories. The process begins with constructing a graph representation from single-cell data, followed by several sophisticated steps:, as related article

• Joint embedding estimation using methods like MOJITOO for multimodal data or PCA for unimodal scRNA-seq data
• Diffusion map construction with Gaussian kernel representation and pseudotime estimation
• Graph refinement through k-nearest neighbor pruning and stress majorization layout algorithms
• Simplicial complex creation using Delaunay triangulation between cellular nodes

The crucial topological manipulation occurs when PHLOWER identifies terminal differentiated cells and root progenitor cells using pseudotime information, then connects them with artificial edges to create holes in the simplicial complex. These holes mathematically correspond to cell differentiation trajectories that can be analyzed through harmonic eigenvectors of the normalized first-order Hodge Laplacian., according to further reading

From Mathematical Abstraction to Biological Insight

PHLOWER transforms abstract mathematical computations into tangible biological discoveries through several key analytical steps. The method samples trajectories from the simplicial complex as edge flows, then creates trajectory embeddings by computing dot products between individual edge flows and harmonic eigenvectors. Each point in this embedding space represents a specific differentiation trajectory., according to recent studies

Through clustering analysis in this trajectory space, PHLOWER identifies major trajectory groups and builds cumulative trajectory spaces that enable reconstruction of complete differentiation trees. The output includes:

• Tree structures showing branching relationships between cell states
• Cell-to-branch associations precisely allocating each cell within specific differentiation paths
• Refined pseudotime estimates providing temporal ordering of differentiation events
• Branch-specific regulator detection identifying transcription factors with branch-specific expression patterns

Current Limitations and Future Directions

While PHLOWER represents a significant advance in trajectory inference, the method currently focuses exclusively on the harmonic components of Hodge decomposition. Future developments could incorporate additional components like curl and gradient terms, enabling analysis of more complex differentiation structures including acyclic graphs.

The methodology shows particular promise for emerging three-dimensional molecular data applications, such as protein-ligand prediction and three-dimensional spatial transcriptomics. In these geometric contexts, higher-order structures like tetrahedrons (3-simplices) could reveal additional geometric features including hulls or voids, though this would require developing efficient numerical methods for higher-order Hodge Laplacian decompositions.

Practical Applications and Implementation

PHLOWER has been validated on both multimodal single-cell sequencing data (combining ATAC and RNA modalities) and unimodal scRNA-seq data. The method’s robustness stems from its integration of established computational biology approaches with novel topological analysis, creating a pipeline that transforms raw single-cell data into comprehensive differentiation maps.

For researchers interested in exploring similar trajectory inference methods, the dynverse/dynbenchmark repository provides valuable benchmarking resources, while technologies like those described in the 10x Genomics Multiome ATAC+GEX platform enable the multimodal data collection that methods like PHLOWER can leverage.

As single-cell technologies continue to advance, topological approaches like PHLOWER offer increasingly powerful frameworks for deciphering the complex choreography of cellular differentiation—transforming mathematical abstractions into biological understanding that could ultimately inform developmental biology, disease mechanisms, and therapeutic development.
